Installation
TheBM-Solar programmingmodule canbe integratedinto the
SMsolarmoduleorcanbeusedasremotecontrolinconjunction
withawallmountingbase.
WhenintegratingtheBM-Solarinthesolarmodule,allsettings
aremadeatthesolarmodule.
The electrical connection must only be carried out by a
qualiedelectrician.
- SwitchOFFthepoweratthesolarmodule
- Removethefaciafromthesolarmodule
- ClicktheBM-Solarprogrammingmoduleintothesolar
moduleasshowninthediagram
- SwitchONthepoweratthesolarmodule
Module installation
Remote control Fittedtoawallmountingbase(partno.2744275),theBM-Solar
programmingunitcanbeusedasaremotecontrol(e.g.inthe
livingroom).
Onlyatwo-wireBUSisrequiredfortheuseasremotecontrol.
Wall mounting base
installation
- Removethewallmountingbasefromitspacking.
- Secure the wall mounting base on a ush-mounting box
(Ø55mm)ordirectlyonthewall.
Wallmountingbase
Fixingholes Fixingholes
