Overview
Rotary selector with
pushbutton function
ON / OFF
pushbutton
Status display
Solar circuit pump
Info
pushbutton
▪ Inthetoplineofthestandarddisplay,thecurrentsolar cylinder
temperature is shown; the bottom line shows the current
collector temperature.
▪ Insystemswithtwocylinders,thesolarcylindertemperatureof
cylinder1isshown.
▪ Insystemswithtwocollectorarrays,thecollectortemperature
ofcollectorarray1isshown.
▪ The BUS symbol indicates that a BUS connection exists
betweentheprogrammingmoduleandtheSMsolarmodule.
TheBUSconnectionisfaultyifthissymbolisnotdisplayed.
Thiswouldpreventthesolarmodulefrombeingoperated.
An arrow on the status display signals which output of the
connectedsolarmoduleiscurrentlyactive.
Standard display
Solarcylindertemperature,cylinder1
BUSsymbol
Collectortemperature,collectorarray1
Statusdisplay,outputA4
Statusdisplay,solarcircuitpump1and
outputsA1-A3
Display
In conjunction with
Status display SM1 solar module SM2 solar module
Solarcircuitpump Solarcircuitpump1
A1 - OutputA1*
A2 - OutputA2*
A3 - OutputA3*
-** - OutputA4*
Status display
* Outputassignmentsubjecttoconguration.
** AnactiveoutputA4issignalledbyanarrowpointingdownwards.
