Installation
Electrical connection
Remote control
Theelectricalconnectionmustonlybecarriedoutbyaqualied
electrician.
Neverroutesensorleadsalongsidemainspowercables.
- SwitchOFFthepoweratthesolarmodule
- Wire the wall mounting base with a two-core cable (minimum
cross-section0.5mm²)inaccordancewiththediagramshown
- ClicktheBM-Solarprogrammingmoduleintothewallmounting
baseasshowninthediagram
- SwitchONthepoweratthesolarmodule
green
eBus
Greenplugof
thesolarmodule
Terminalstrip
Wallmountingbase
