Wolf BM-Solar - Parameter Settings - SM2 Solar Module (Part 1); Parameters for SM2 Solar Module (Cylinders 1-2)

16 3061916_0611
Parameter
BM
Parameter
BM-Solar
Explanation
Setting range Factory
setting
min. max.
SOL 01 P 01
Startdifferentialsolarcylinder1 5K 30K 8K
SOL 02 p 02
Stopdifferentialsolarcylinder1 2K 20K 4K
SOL 03 P 03
Collectorcoolingfunction 0(OFF) 1(ON) 0
SOL 04 P 04
Criticalcollectortemperature 90°C 150°C 110°C
SOL 05 P 05
Maximumcollectortemperature 100°C 150°C 130°C
SOL 06 P 06
Maximumtemperature,solar
cylinder1
15°C 90°C 60°C
SOL 07 P 07
Assignment,solarcylinder1 0 8 0
SOL 08 P 08
Capturingtheamountofheat 0(OFF) 4 0
SOL 09 P 09
P 08=0→P 09 Notadjustable
P 08=1→
Pulsevalue,pulsegenerator
P 08=2→
Constantflowrate
P 08=3or4→
Pulsevalue
externalheatmeter
0l/pulse
0l/min
-2
99.5l/pulse
99.5l/min
1
1l/pulse
1l/min
0
SOL 10 P 10
Glycolselection:
0=Water
1=TyfocorL(Anro)
2=TyfocorLS(AnroLS)
3=Propyleneglycol
4=Ethyleneglycol
0 4 1
SOL 11 p 11
BUSfeed 0 2 2
SOL 12 p 12
Conguration 1 14 1
SOL 13 p 13
Speedcontrol,solarcircuitpump 0(OFF) 1(ON) 0
SOL 14 p 14
Startdifferentialsolarcylinder2 5K 30K 8K
SOL 15 p 15
Stopdifferentialsolarcylinder2 2K 20K 4K
SOL 16 p 16
Maximumtemperature,solar
cylinder2
15°C 90°C 60°C
SOL 17 p 17
Assignment,solarcylinder2 0 8 8
SOL 18 p 18
Burnerblockedduring
returntemperatureraising
0s 300s 0s
SOL 19 p 19
Startdifferential,return
temperatureraising
4K 30K 10K
SOL 20 p 20
Stopdifferential,return
temperatureraising
2K 20K 5K
SOL 21 p 21
Prioritysolarcylinder1 0 2 0
SOL 22 p 22
Startdifferential
parallelcylinderoperation
20K 60K 30K
SOL 23 p 23
Differentialtemperature,bypass 8K 50K 15K
SOL 24 p 24
FunctionoutputA4 0(OFF) 3 0
SOL 25 p 25
Starttemperature,thermostat
function
30°C 90°C 50°C
SOL 26 p 26
Stopdifferential,thermostat
function1/2
5K 30K 10K
SOL 27 p 27
Tubecollectorfunction 0(OFF) 2 0
SOL 28 p 28
Frostprotectionfunction 0(OFF) 1(ON) 0
Parameters used with SM2 solar module:
Parameter level
