13.Sparepartslist
CFL 10 - WRG
Pos. Designation Comments Mat.no.
1 Supply air fan incl. front plate CFL250-0,48-2970 2137980
2 Extract air fan incl. front plate CFL250-0,48-2970 2137980
3 M5 compact lter, extract air W287 x H389 x D48 1668944
4 F7 compact lter, outdoor air W287 x H389 x D48 1668945
5 Differential pressure switch JDL-112 2738360
6 Countercurrent plate heat exchanger GS 30 / 390 2980940
7 Servomotor for bypass damper CM24-SR-F10-R-WLF 2269611
8 Pluggable temperature sensor 2799058
9 Inspection door partition 6217979
10a
CFL-WRG inspection door, operating side, supply air right
6217981
10b
CFL-WRG inspection door, operating side, supply air left
6218904
CFL 15 - WRG
Pos. Designation Comments Mat.no.
1 Supply air fan incl. front plate CFL250-0,75-3450 2137864
2 Extract air fan incl. front plate CFL250-0,75-3450 2137864
3 M5 compact lter, extract air W592 x H287 x D48 1668826
4 F7 compact lter, outdoor air W592 x H287 x D48 1668827
5 Differential pressure switch JDL-112 2738360
6 Countercurrent plate heat exchanger GS 30 / 570 2980929
7 Servomotor for bypass damper CM24-SR-F10-R-WLF 2269611
8 Pluggable temperature sensor 2799058
9 Inspection door partition 6217979
10a
CFL-WRG inspection door, operating side, supply air right
6217992
10b
CFL-WRG inspection door, operating side, supply air left
6218906
CFL 22 - WRG
Pos. Designation Comments Mat.no.
1 Supply air fan incl. front plate CFL280-0,715-2800 2137934
2 Extract air fan incl. front plate CFL280-0,715-2800 2137934
3 M5 compact lter, extract air W795 x H333 x D48 1668954
4 F7 compact lter, outdoor air W795 x H333 x D48 1668955
5 Differential pressure switch JDL-112 2738360
6 Countercurrent plate heat exchanger GS 35 / 500 2980989
7 Servomotor for bypass damper CM24-SR-F10-R-WLF 2269611
8 Pluggable temperature sensor 2799058
9 Inspection door partition 6217980
10a
CFL-WRG inspection door, operating side, supply air right
6217982
10b
CFL-WRG inspection door, operating side, supply air left
6218905
