Wolf CFL-WRG - 5 Specification

93065065_201704
5.Specication
Specication
Size CFL 10-WRG 15-WRG 22-WRG 32-WRG
Max. air volume m³/h 1000 1500 2200 3200
at available ext. pressure, supply air
at available ext. pressure, extract air
Pa
Pa
270
295
380
395
220
170
600
610
Heat recovery rate % > 90 > 90 > 90 > 90
Height A mm 367 367 411 495
Width B mm 1017 1423 1830 1932
Length C mm 1322 1322 1525 1932
Control panel width D mm 115 115 115 -
Internal duct connection dimensions mm 409 x 247 612 x 247 815 x 291 866 x 354
Weight kg 130 160 240 340
Motor data for each fan CFL 10-WRG 15-WRG 22-WRG 32-WRG
Mains voltage V 1 x 230 V 1 x 230 V 1 x 230 V 3 x 400 V
Frequency Hz 50 / 60 50 / 60 50 / 60 50 / 60
Max. power consumption W 480 750 715 1650
Max. current consumption A 2.1 3.3 3.1 2.5
Speed rpm 2970 3450 2800 3140
Energy efciency class IE 4 IE 4 IE 4 IE 4
IP rating IP 54 IP 54 IP 54 IP 54
Protection class Iso B Iso B Iso B Iso B
Power cable CFL 10-WRG-PWW 15-WRG-PWW 22-WRG-PWW 32-WRG-PWW
Supply voltage V 1 x 230 V 3 x 400 V 3 x 400 V 3 x 400 V
Cable cross-section mm² 3 x 1.5 mm² 5 x 1.5 mm² 5 x 1.5 mm² 5 x 2.5 mm²
On-site fuse A 16 A 16 A 16 A 20 A
Power cable CFL 10-WRG-E-Reg. 15-WRG-E-Reg. 22-WRG-E-Reg. 32-WRG-E-Reg.
Supply voltage V 1 x 230 V 3 x 400 V 3 x 400 V 3 x 400 V
Cable cross-section mm² 3 x 1.5 mm² 5 x 2.5 mm² 5 x 2.5 mm² 5 x 6 mm²
On-site fuse A 16 A 20 A 20 A 35 A
