MF130 SPECIFICATIONS
Dust/Chip Extractor Specifications
6
6-5 doc101521 MF130 SPECIFICATIONS
See table 6-7. A relation between the pattern knife protrusion and the thickness is shown below.
See table 6-8. Rotating tools .
6.3 Dust/Chip Extractor Specifications
See Table 6-9. Specifications of the dust/chip extractors used on the MF130 are listed below.
IMPORTANT! The dust extractor hoses must be grounded or made
with materials not accumulating electrostatic charge.
CAUTION! Always turn on the dust extractor before starting the
machine
Pattern knife thickness Pattern knife max.
protrusion
1
1
According to EN 847-1:2005 European Standard
3 mm 13 mm
4 mm 21 mm
5mm 29 mm
TABLE 6-7
1
1
According to EN 847-1:2005 European Standard
30 mm spindle tools with shaft
Tool Max diameter 195 mm 100 mm
Cutter types MAN
allowed for manual feed
MAN
allowed for manual feed
Must be allowed for speeds up to... 9 000 rpm 14 000 rpm
TABLE 6-8
Airflow
1000 m
3
/h
Inlet diameter 1x100mm
Pressure Drop 1.5 kPa (0.25
psi)
1
1
The pressure drop between the inlet of the capture device and
the connection to the CADES should not exceed 1.5 kPa
(for the nominal air flow rate). If the pressure drop exceeds
1.5 kPa the machine might not be compatible with
conventional CADES.
Recommended conveying air
velocity in the duct
25 m/s
TABLE 6-9
