1. The installation and components of equipment
1.1 Instruction
Guilin Woodpecker Medical Instrument Co., Ltd. is a professional
manufacturer in researching, developing and producing ultrasonic scalers. The
product is mainly used for teeth cleaning and also an indispensable equipment for
teeth disease prevention and treatment. The new product UDS-E ultrasonic scaler
has scaling, perio, endo and auto-water supply functions with the following
features:
1.1.1 With auto-water supply function, easier operation.
1.1.2 The inner water pipe is made from antiseptic material, clinical uids,
such as Hydrogen peroxide, chlorhexidine and sodium Hypochlorite, etc,
can be used perfectly under the mode of auto-water supply system so that the
performance of perio and endo is improved dramatically.
1.1.3 The handpiece is detachable and can be autoclaved to the temperature of
134°C and the pressure of 0.22MPa.
1.1.4 Automatic frequency tracking ensures that the machine always works on
the best frequency and performs more steadily.
1.1.5 Controlled by PC, easy operation and more ecient for scaling.
These features make UDS-E become a new generation product in the world
dental market.
1.2 Components
1.2.1 The components of machine are listed in the packing list.
1.2.2 Product performance and structure
Ultrasonic scaler is composed of electrocircuit, water way and ultrasonic
transducer.
1.2.3 Scope of application
Ultrasonic scaler UDS-E is used for the dental calculus elimination and root
canal treatment.
1.3 The main technical specications
1.3.1 Power supply Input: 220-240V~ 50Hz/60Hz 150mA
1.3.2 Main unit input: 24V~ l.3A
1.3.3 Output primary tip vibration excursion: ≤100μm
1.3.4 Output half-excursion force: <2N
1.3.5 Output tip vibration frequency: 28kHz±3kHz
1.3.6 Output power: 3W to 20W
1.3.7 Main unit fuse: Tl.6AL 250V
1.3.8 Power supply fuse: T0.5AL 250V
1.3.9 Weight of main unit: 1.17kg
1.3.10 Weight of power supply: 1 kg
