Tips and recommendations
This symbol indicates useful tips and recommendations as well as information for
ecient and trouble-free operation.
Additional markings
To emphasize instructions, results, lists, references, and other elements, the following
markings are used in these instructions:
Marking Explanation
⚙ Start of a procedure list
> Prerequisite for a procedure list
▷ Step-by-step instructions
▶ Results of action steps
╚═▷ References to sections of these instructions and to other relevant
documents
• Listing without xed sequence
☼ Example
»Buttons« Operating elements (e.g. buttons, switches), display elements (e.g.
signal lamps)
»Display« Screen elements (e.g. buttons, programming of function keys)
[Screen xx / Screen xy / Screen
xz] ...
Menu path.
The following information and setting refer to a page on HMI screen or
ToolKit located as described here.
Some parameters/settings/screens are available only either in ToolKit or
in HMI/display.
Dimensions in Figures
All dimensions shown with no units specied are in mm.
1.2.1
Copyright And Disclaimer
Disclaimer
All information and instructions in this manual have been provided under due
consideration of applicable guidelines and regulations, the current and known state of the
art, as well as our many years of in-house experience. Woodward assumes no liability for
any damages due to:
• Failure to comply with the instructions in this manual
• Improper use / misuse
• Willful operation by non-authorized persons
• Unauthorized conversions or non-approved technical modications
8 easYgen | exciter-10 B37910
1 General information
1.2.1 Copyright And Disclaimer
