Worcester danesmoor 26/32

4
28 Sec. Kerosene 0.40 60°ES 135 1.11 1.41 195 9.5 8.0 13.5 46,000 12 41,000
28 Sec. Kerosene 0.50 60°ES 100 1.30 1.64 210 10.5 8.5 15.5 53,000 14 48,000
NOMINAL BOILER RATING AT NORMAL OPERATING TEMPERATURE
12/14 Table 2. Electro Oil Inter B9A Burner (See Fig. 21)
Fuel Nozzle
Pump
Pressure
(p.s.i.)
Fuel Flow
Rate
Flue Gas
Temp.
(°C)**
%CO
2
Approx.
Air
Setting
Appliance
Input
kW Btu/hr kW Btu/hr
Output
Kg/h l/h
28 Sec. Kerosene 0.50 60°ES 110 1.40 1.77 215 10.5 8.5 17 58,000 15 51,000
28 Sec. Kerosene 0.55 80°EH 100 1.59 2.01 225 10.5 8.75 19 65,000 17 58,000
28 Sec. Kerosene 0.60 60°ES 105 1.78 2.25 235 11.5 9.0 21.5 73,000 19 65,000
35 Sec. Gas Oil* 0.50 80°S 155 1.80 2.12 235 11.5 9.0 21.5 73,000 19 65,000
NOMINAL BOILER RATING AT NORMAL OPERATING TEMPERATURE
15/19 Table 3. Electro Oil Inter B9B Burner (See Fig. 21)
Fuel Nozzle
Pump
Pressure
(p.s.i.)
Fuel Flow
Rate
Flue Gas
Temp.
(°C)**
%CO
2
Approx.
Air
Setting
Appliance
Input
kW Btu/hr kW Btu/hr
Output
Kg/h l/h
28 Sec. Kerosene 0.60 80°EH 110 1.87 2.37 215 10.5 6.0 22.5 77,000 20 68,000
28 Sec. Kerosene 0.75 80°EH 115 2.10 2.66 225 10.5 7.0 25 86,000 22.5 77,000
28 Sec. Kerosene 0.75 80°EH 135 2.34 2.96 240 11.5 7.5 28 96,000 25 85,000
35 Sec. Gas Oil* 0.60 80°S 130 2.13 2.51 225 11.0 7.25 25 86,000 22.5 77,000
35 Sec. Gas Oil* 0.60 80°S 160 2.37 2.79 240 11.5 8.0 28 96,000 25 85,000
NOMINAL BOILER RATING AT NORMAL OPERATING TEMPERATURE
20/25 Table 4. Electro Oil Inter B11C Burner (See Fig. 22) Conventional Flue Appliance (CF/LLD)
Fuel Nozzle
Pump
Pressure
(p.s.i.)
Fuel Flow
Rate
Flue Gas
Temp.
(°C)**
%CO
2
Approx.
Air
Setting
Appliance
Input
kW Btu/hr kW Btu/hr
Output
Kg/h l/h
28 Sec. Kerosene 0.60 80°EH 110 1.87 2.37 215 10.5-11.0 6.0 22.5 77,000 20 68,000
28 Sec. Kerosene 0.75 80°EH 115 2.10 2.66 225 11.0-11.5 7.0 25 86,000 22.5 77,000
28 Sec. Kerosene 0.75 80°EH 135 2.34 2.96 240 11.5-12.0 7.5 28 96,000 25 85,000
NOMINAL BOILER RATING AT NORMAL OPERATING TEMPERATURE
20/25 Table 5. Electro Oil Inter B11C Burner (See Fig. 22) RS Balanced Flue Appliance
Fuel Nozzle
Pump
Pressure
(p.s.i.)
Fuel Flow
Rate
Flue Gas
Temp.
(°C)**
%CO
2
Approx.
Air
Setting
Appliance
Input
kW Btu/hr kW Btu/hr
Output
Kg/h l/h
28 Sec. Kerosene 0.85 80°EH 110 2.36 2.99 225 11.0-11.5 11 28.5 97,000 26 89,000
28 Sec. Kerosene 0.85 80°EH 145 2.66 3.37 240 11.0-11.5 12 32 109,000 29 99,000
28 Sec. Kerosene 1.00 80°EH 130 2.95 3.74 245 11.5-12.0 16 35.5 121,000 32 109,000
35 Sec. Gas Oil* 0.50 80°H 260 2.44 2.87 220 11.5-12.0 9 28.5 97,000 26 89,000
35 Sec. Gas Oil* 0.55 80°H 265 2.76 3.25 235 11.5-12.0 14 32 109,000 29 99,000
35 Sec. Gas Oil* 0.55 80°H 330 3.06 3.60 240 12.0-12.5 16 35.5 121,000 32 109,000
NOMINAL BOILER RATING AT NORMAL OPERATING TEMPERATURE
26/32 Table 6. Electro Oil Sterling 40 Burner (See Fig. 23) Conventional Flue Appliance (CF/LLD)
Fuel Nozzle
Pump
Pressure
(p.s.i.)
Fuel Flow
Rate
Flue Gas
Temp.
(°C)**
%CO
2
Approx.
Air
Setting
Appliance
Input
kW Btu/hr kW Btu/hr
Output
Kg/h l/h
