Worcester GB162-80

TECHNICAL SPECIFICATIONS
6 720 648 726 (2011/07)
90
81 Electronic connection orange 73777
82 Flue gas exhaust connection 7746900414
83 Flue gas adapter 73936
84 Measure nipple cap 73937
85 Seal 125 mm 7746900323
86 Cable harness low voltage 73944
87 Cable harness high voltage 73945
88 Cable harness on/off switch 73946
89 Cable harness earth 73947
90 Mains cable 7101471
91 Union nut 1½" (5 pc) 73481s
92 Seal (10 pc) 15022s
93 Nut 1" 73675
95 Gas valve 73960
96 Pump UPER 25-80-130 73955
97 Drain cock 73409
100 Casing 73961
101 Thermometer 73890
102 Manometer 73958
103 Safety valve 73956
104 Clip (5 pc) 73651s
105 Seal (5 pc) 73638s
106 Drain cock 73959
107 Connection pressure gauge 73081
108 Drain pipe 73075
109 Plug protector 73948
120 230 Volt converter with box 78079
121 230 Volt converter 78091
122 Pipe three way valve/boiler 73076
123 Pipe three way valve/
connection set
73077
124 Return pipe hot water tank 73078
125 Pipe straight DN 25mm
L=30cm
73079
126 Body three way valve 20374
127 Motor three way valve 20375
128 Three way valve complete 20373
129 Check valve 74551
Description Product No.
130 Repair set three way valve 1”+
5/4”
75400
131 Valve housing supply (single) 74547
Valve housing supply (combi) 74548
132 Valve housing return (single) 74549
Valve housing return (combi) 74550
– Screw 6.3 x 19 (10 pc) 73986
– Clip suction pipe 73053
Spare part boiler
– Hot water sensor 73316
– Adapter cable boiler sensor 73754
– Adapter cable three way valve 73753
– Wire hot water tank 74552
– Sensor locking pin 73495
– Conversion set 7746900509
– Flue gas adapter DN 160-80
with the following spare parts
7101422
– Cap flue gas adapter
DN 160-80
7101418
– Seal DN 110 7101492
– Seal DN 160 7101494
Description Product No.
