Worcester Greenstar Highflow 550CDi

INSTALLATION
INSTALLATION & SERVICING INSTRUCTIONS
24
FLUE MEASURING & CUTTING
8 716 115 219c (03.2010)
FLUE MEASURING & CUTTING
FLUE OUTLETS (L or P):
1
Remove seal (B) from flue adaptor (A).
2
Cut square to mark, as shown, deburr
and clean.
3
Replace seal (B).
L
P
L
L
P
A B
A
B
B
1
2
3
1
3
2
