Worcester GREENSTAR i SYSTEM

13
SERVICE CLEARANCES
6 720 644 864a (2010/10)
5 SERVICE CLEARANCES
Your installer will have provided adequate space around the boiler for safety and servicing access.
Fig. 8 Service clearances
CAUTION: Restricted space.
The boiler may overheat.
B Do not restrict this space with the addition of cupboards, shelves etc. next to the
boiler.
+ 30 mm
above elbow
5 mm
600 mm
5 mm
200 mm
6720643356-01.1Wo
