ABOUT THE APPLIANCE
6 720 803 688 (2012/11) 5
2.5 OVERVIEW OF COMPONENTS
2.5.1 GREENSTAR PLUS HYBRID MANAGER (INTERNAL UNIT)
Fig. 2 Main components of the hybrid manager
[1] Refrigerant lines for the refrigerant (R410A)
[2] Casing
[3] Water pipe connections
2.5.2 GREENSTAR PLUS EXTERNAL UNIT
Fig. 3 Main components and casing of external unit
[4] Top casing panel
[5] Service panel
[6] Front of casing panel
[7] Air grille
[-] Finned heat exchanger (evaporator) at the rear of the external
unit
6720803688-02.1Wo
1
2
3
6720803688-03.1Wo
7
4
5
6
