6 720 611 400 GB (03.11)
18
Installation
Fig. 18 Flue with One Extension
Fig. 19 Flue with Extensions
Fig. 20 Flue Components
3.9.3 Flue duct preparation and assembly
Measure the flue length L. Refer to fig. 21, 22.
Maximum 1600mm
Clamp
Flue
Turret
Terminal
Assembly
Outer
Wa ll
6 720 610 599 - 00.TD
Extension
Duct
Clamp
Flue
Turret
Terminal
Assembly
Outer
Wall
6 720 610 599 - 01.TD
Extension
Duct
Extension
Duct
ClampClamp
Clamp
Flue
Turret
Extension Flue Duct
Flue Terminal Wall Sealing Gasket
6 720 610 599 - 01.TD
