ENGLISH
11
Single Mode
Modo Duble Preset
Mix Mode
All programs will run in sequential order starting in the order of program number.
The Segment Display will read the running program number.
All programs will be controlled by the same Speed Slider.
Press the MODE SELECT BUTTON and select "CHNS < > SCENES".
Press the PARK BUTTON to select MIX CHASE MODE. A red LED will indicate this selection.
Will run all programs synchronously.
All programs can be controlled by the same SLIDER SPEED, or each programs speed may be controlled individually. (See Speed Setting).
Press the MODE SELECT BUTTON and select "CHNS <> SCENES".
Press the PARK BUTTON to select MIX CHASE MODE. A yellow LED will indicate this selection.
The 3-Digit Segment Display is used to display intensity percentage or absolute DMX value.
To change between percentage and absolute value. Press and hold the Shift Button. While holding down the Shift button press the % or
0-255 Button to switch between percentage and absolute values.
If the Segment Display reads, for example, "076", it means a percentage value 76%. If the Segment Display reads "076", it means the
DMX value 76.
Blind function takes channels temporally out from a chase, when the chase is running, and gives you manual control over the channel.
Press and hold the Blind Button and tap the relative Flash Button you want temporarily take out of the chase.
To return to normal chase again press and hold the Home Button and push the Flash Button you want to return normal chase.
In CHNS < > SCENES Mode, press down the button you can change the chasing mode of programs between Single Mode and Mix Mode.
In Double Preset Mode, pressing down this button is equal to pushing Master Slider B to the top.
In Single Preset Mode, this button could temporally record current output, with Master Slider B to adjust.
The ADD/KILL Button changes the mode of the flash buttons. Normally the flash buttons are in Add mode, whereas pressing any flash
button will not kill other scenes, allowing multiple scenes to be on at a time.
The Kill mode is activated by pressing the Add/Kill button and illuminating the LED above it. Pressing any flash button will kill other active
SCENE or Program.
In Kill Mode, the killed program does not stop running but can not output.
Press Mode Select Button to enter A double Preset Mode.
In this mode, Channel Slider 1 - 24 (* 1 - 12) and channel sliders 25 - 48 (* 13 - 24) both control Channel 1 - 24 (* 1 - 12).
Master A controls channel Slider 1 - 24 (* 1 - 12) while Master B controls Channels Sliders 25 - 48 (* 13 - 24).
In this Mode, no scene could be recorded.
Dimmer Display
Blind and Home
Park
Add - Kill
Example
Enter the Double Preset Mode.
Push Channel Slider 1 to 6 to the and move Channel Sliders 19 to 24 to the maximum.
Move Master A and B to the same level and push them to the same direction, you will get a scene.
Technical Specifications
Power Input
DMX Output
MIDI Signal
Audio Input
Fuse (internal)
Weight
DC 12 - 20 V. 500 mA. min.
3 pin female XLR
5 pin standard Interface
100 mV - 1 Vpp.
Fo. 5A 250V 5x20 mm
7,2 K. (* 4,6)
To retain your programs from loss, this unit must be powered not lees than two hour every month.
The Segment Display shows "LOP" if the voltage is too low.
Attention!
