Functions
USA
18
Measurements
You can perform different measure-
ments with the caliper:
• Outer measurement
16
: Use
the outside measurement
scale
14
.
• Depth measurement
17
: Use
the depth blade
10
.
• Step measurement
18
: Use the
step measuring scale
15
.
• Inside measurement
19
: Use
the inside measurement
scale
4
.
16
17
18
19
