The Parameter control encoders
3.1.7 The pads/preset buttons
The eight large buttons arranged across the front of the MINI serve a dual purpose. Their exact duties are determined
by the state of the Shift and Pads buttons.
For example: The pads can be assigned to trigger up to sixteen particular MIDI notes (drums, stabs, bass notes,
whatever). When the Pads 1-8/9-16 button is not lit, the first bank of pads is active (1-8). When the Pads 1-8/9-16 button
is lit, the second bank of pads is active (9-16).
However, when used in conjunction with the Shift button, the pads will recall one of eight MIDI presets. This is
accomplished by holding the Shift button and pressing one of the pads.
The pads/ preset buttons
3.2 Side panel overview
The side panel of the MMINI contains two important connectors: the footswitch jack and a USB Type B jack.
Side panel
The footswitch jack functions as an on/off switch and can be configured for either momentary applications (such as
sustain pedal) or latching behavior (first press/release sends one event, second press/release sends the next event).
