Limbing and Trimming Electric Chain Saw
EN
98
1. POWER CORD
2. LOCK OUT BUTTON
3. REAR HANDLE
4. TRIGGER SWITCH
5. OIL LEVEL WINDOW
6. OIL FILLER
7. FRONT HANDLE
8. MOTOR
9. JAW TEETH
10. GUIDE BAR
11. SAW CHAIN
12. CHAIN ACCESS COVER
13. CHAIN ACCESS COVER NUT
14. AUXILIARY POSITION
15. CHAIN TENSIONING BOLT
16. SPROCKET
17. LOCK PIN
18. LOCK PIN RECEPTACLE (See Fig. B3)
19. OIL BOTTLE
20. EXTENSION POLE (See Fig. Z4)
21. EXTENSION CORD RETAINER
Not all the accessories illustrated or described are included in standard delivery.
