STEPS IF YOU ARE USING THE INSIDE ENTRY GLANDS
27. Remove the screws from both inside entry glands and the back base plate.
28. Route the laser head and/or laser cable from the bottom of the enclosure. Perform steps 11-
19.
29. Reinstall the back base plate.
30. Locate the empty cable entry gland removed from in step 27 and disassemble.
31. Place a single properly sized cable glands around each cable
32. Arrange and load the glands in a manner allowing placement into each half of the black
plastic cable entry housing.
33. Re-install the two long chrome plated ¼”-20 cap screws back into the edge of the cable
entry gland firmly locking the cables into place on the back panel. The screw is to thread into
the nuts on the opposite side of the housing.
34. Place the cable entry gland onto the back base plate using the four SHCS M5 screws which
were taken out in step 27. Secure both cable entry gland housing to the back base plate.
