Worx WG118E User Manual

11
2-in-1 Grass Trimmer/Edger WG118E
separate piece of line on lower section of Spool (See
Fig. L2 & L3).
Leave approximately 100mm of line unwound and
place it into the cleat. Repeat on the lower section of
the Spool.
Care should be taken to ensure that the line is neatly
coiled on the Spool (See Fig L4). Failure to do so will
impair the efficiency of the automatic line feed.
Then fit the Spool as described above in “Changing
the Line Spool”.
MAINTENANCE
After use, disconnect the machine from the electrical
outlet and check for damage. Your trimmer requires
no additional lubrication or maintenance. There are no
user serviceable parts in your trimmer. Electric powered
trimmers should only be repaired by an authorized
repairer. Use only manufacturers recommended
replacement parts and accessories.
Never use water or chemical cleaners to clean your
trimmer. Wipe clean with a dry cloth. Always store
your trimmer in a dry place out of the reach of children.
Keep the motor ventilation slots clean. If you see some
sparks flashing in the ventilation slots, this is normal
and will not damage your trimmer.
b
a
A
B
C
D
E1
E2
F
G
H1
16
H2
I
J
15
11
12
13
14
K
L1
L2
L3
L4
RIGHT
WRONG
b
a
A
B
C
D
E1
E2
F
G
H1
16
H2
I
J
15
11
12
13
14
K
L1
L2
L3
L4
RIGHT
WRONG

Worx WG118E Specifications

General

Product color	Black, Orange, Silver
No-load stroke rate	8900 spm
Engine power	550 W
Power source	Electric AC
Battery voltage	18 V
AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz
Type	String trimmer
Head type	Nylon line
Telescopic	Yes
Handle type	-
Line diameter	1.65 mm
Blade material	Nylon
Rotational speed	8900 RPM
Sound power level	96 dB
Vibration emission	5.7 m/s²
Line length supplied	10 m
Sound pressure level	85 dB
Cutting diameter (max)	300 mm

Weight and Dimensions

Weight	2800 g
