9
Electric Lawn Mower WG705E
2. GRASS COLLECTION BAG ASSEMBLY
Connect the grass box handle to the box top as shown
in Fig. B1-B4.
1) Press the front of the handle briefly (See Fig. B2).
2) Then push it forward (See Fig. B2).
3) Push down the back of the handle (See Fig. B2).
4) Finally, clip the plastic clips over the metal frame
(See Fig. B3).
WARNING: Don’t fit the handle in reversed
direction. Fit the handle as shown in Fig B1.
Front Part
Back Part
B1
1
2
3
B2
B3
B4
