8
Electric Lawn Mower WG705E
INTENDED USE
This product is intended for domestic lawn
mowing.
ASSEMBLY
IMPORTANT! Before you assemble the lawn
mower, check the accessories according above
information, make sure the accessories are completed.
1. FITTING THE HANDLE (See Fig. A1, A2, A3)
Remove the screws (X 2) on the both side of poles.
1) Insert the lower handle (8) into the holes provided.
2) Secure with the screws (See Fig. A1).
3) Attach the upper handle (6) with the bolts and
handle knobs (7) to the lower handle (8) (See Fig.
A2).
NOTE: Ensure the bolts are fully inserted through the
handles before fitting the handle knobs.
Attach the cable clips (3) provided, to the upper and
lower handle. Insert the cable into the clips ensuring
there is enough cable slack. (See Fig. A3)
A1
A2
3
A3
