Worx WX423 User Manual

Electric Circular Saw EN
15
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE:
The tool is intended for ripping and cross-
cutting wood and other materials in straight
cutting lines, while resting firmly on the work
piece.
ASSEMBLY AND OPERATION
Action Figure
Saw blade Assembly and
Removing
See Fig. A
Safety On/Off Switch See Fig. B
Sawdust Removal See Fig. C
Cross and Rip Cutting See Fig. D1, D2
Parallel Guide See Fig. E1, E2
Cutting Depth Adjusting See Fig. F1, F2
Pocket Cutting
See Fig. G1,
G2, G3, G4, G5
WORKING HINTS FOR YOUR
TOOL
If your power tool becomes too hot, please
run your circular saw no load for 2-3 minutes
to cool the motor. Avoid prolonged usage at
very low speeds.
Protect saw blades against impact and shock.
Cutting with extreme force can significantly
reduces the performance capability of the tool
and reduces the service life of the saw blade.
Sawing performance and cutting quality
depend essentially on the condition and the
tooth count of the saw blade. Therefore, use
only sharp saw blades that are suited for the
material being cut.
Choice of blades: 24 teeth for general work,
approx. 40 teeth for finer cuts, more than 40
teeth for very fine cuts into delicate surfaces,
diamond for tile, cement board, etc.
Only use saw blades recommended.
MAINTAIN TOOLS WITH
CARE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Keep tools sharp and clean for better and
safer performance. Follow instructions for
lubricating and changing accessories. Inspect
tool cords periodically and if damaged, have
repaired by authorized service facility. Your
power tool requires no additional lubrication
or maintenance. There are no user serviceable
parts in your power tool. Never use water or
chemical cleaners to clean your power tool.
Wipe clean with a dry cloth. Always store
your power tool in a dry place. Keep the
motor ventilation slots clean. Keep all working
controls free of dust.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard.
Periodically clear dust and chips from guard
and base to ensure proper performance.
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or retailer for
recycling advice.

Worx WX423 Specifications

General

Blade bore	15 mm
Blade diameter	85 mm
Bevel adjustment	-
Idle speed (max)	3600 RPM
Cutting depth (90º)	27 mm
Input power	400 W
Power source	AC
Spindle lock	Yes
Product color	Black, Orange
Suitable for materials	Metal, Plasterboard, Plastic, Tile, Wood

Weight and Dimensions

Depth	90 mm
Width	320 mm
Height	160 mm
Weight	1400 g
