Worx WX423 User Manual

Electric Circular Saw EN
16
TROUBLE SHOOTING
Symptom Possible Causes Possible Solution
Tool will not start when
operating the on/off switch.
Power cord not plugged in.
Power cord is broken.
Carbon brush has worn
down
Check to make sure power cord
is connected well into a working
outlet.
Unplug the power cord. Replace
it using a qualified maintenance
person.
Replace the carbon brush using a
qualified maintenance person.
Cutting depth is less than
that is set.
Sawdust accumulated at
the rear of the base.
Shake out sawdust. Consider
connecting a vacuum for dust
collection.
Blade spins or slips
Blade is not tightly
engaged with the spindle.
Remove the blade, and
reassemble it as described in
Saw blade Assembly and
Removing section.
Blade will not cut a straight
line.
Blade is dull.
Blade is not mounted
properly.
Saw is not being guided
properly.
Mount a new, sharp blade on
the saw.
Check that blade is properly
mounted.
Use a parallel guide.
Blade kicks back when
beginning a cut
Blade is not spinning fast
enough
Allow the saw blade to reach full
speed prior to beginning a cut in
the material.

Worx WX423 Specifications

General

Blade bore	15 mm
Blade diameter	85 mm
Bevel adjustment	-
Idle speed (max)	3600 RPM
Cutting depth (90º)	27 mm
Input power	400 W
Power source	AC
Spindle lock	Yes
Product color	Black, Orange
Suitable for materials	Metal, Plasterboard, Plastic, Tile, Wood

Weight and Dimensions

Depth	90 mm
Width	320 mm
Height	160 mm
Weight	1400 g
