OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
ASSEMBLY AND OPERATION
Action Figure
Mounting and removing
the blade
See Fig. A
Safety switch and On/Off
trigger
See Fig. B
Cross and rip cutting See Fig. C1, C2
Parallel guide See Fig. D1, D2
Adjusting the cutting
depth
See Fig. E1, E2
Adjusting the cutting angle See Fig. F
Pocket /plunge See Fig. G1,G2
Sawdust removal See Fig. H
Adjusting the Base Plate See Fig. I
WORKING HINTS FOR YOUR
TOOL
Your power tool shall not be used for cutting
plastics. The blade may become very hot after
prolonged usage, please do not touch it.
WARNING-To reduce the
risk of injury, user must read
instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Before any work on the
machine itself, remove the
power cord from the outlet.
Wear protective gloves
Wood
Incorrect
Correct
Lock
Unlock
SYMBOLS
To Next Page
