Compact Circular Saw WX439
COMPONENT LIST
1. SAFETY SWITCH
2. ON/OFF TRIGGER
3. SOFT GRIP HANDLE
4. HEX KEY
5. BLADE GUARD LEVER
6. BLADE GUARD
7. BASE PLATE
8. PARALLEL GUIDE
9. CUTTING MARK, 0°
10. CUTTING MARK, 45°
11. PARALLEL GUIDE CLAMPING FIXTURE
12. BEVEL ADJUSTMENT LEVER
13. DUST EXTRACTION OUTLET
14. VACUUM ADAPTER
15. FIXED UPPER BLADE GUARD
16. SPINDLE LOCK BUTTON
17. DEPTH ADJUSTMENT LEVER
18. BLADE BOLT
19. OUTER FLANGE
20. SAW BLADE
21. INNER FLANGE
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WX439 (4 - designation of machinery, representative of Saw)
Voltage 230–240V~50Hz
Rated power 500W
No load speed 4200/min
Rated speed 4200/min
Blade size TCT blade 120mmx1.5mmx9.5mmx24T
HCS blade 115mmx1.2mmx9.5mmx60T
Abrasive cutting disc 115mmx1.6mmx9.5mmx60G
Bevel capacity 0-45°
Cutting capacity Cutting Depth at 90° 46mm
Cutting Depth at 45° 30mm
Arbor Size 9.5mm
Recommended maximum material thickness Wood 46mm
Aluminum 2.5mm
PVC pipe (diameter) 46mm
Tile 12mm
Sheet steel 0.5mm
Saw blade thickness TCT blade 1mm
HCS blade 1mm
Abrasive cutting disc 1mm
Spindle thread size M6
Protection class
/ll
Bare tool weight 1.9kg
