Worx WX445 Original Instruction

Circular saw with laser EN
6
1. LOCK-OFF BUTTON
2. ON/OFF SWITCH
3. LASER ON/OFF SWITCH
4. FRONT HANDLE
5. BASE PLATE ANGLE SCALE
6. BASE PLATE BEVEL LOCK
7. PARALLEL GUIDE
8. BASE PLATE
9. PARALLEL GUIDE LOCK KNOB
10. SPINDLE LOCK BUTTON
11. LASER GUIDE
12. OUTER FLANGE
13. LOWER GUARD
14. SAW BLADE*
15. BLADE BOLT
16. LOWER GUARD LEVER
17. VACUUM ADAPTER
18. REAR HANDLE
19. DEPTH OF CUT SCALE
20. HEX KEY
21. DEPTH OF CUT ADJUSTMENT LEVER
22. INNER FLANGE (See Fig. G)
*Not all the accessories illustrated or described are included in standard delivery.

Worx WX445 Specifications

General

Blade diameter	190 mm
Number of teeth	24
Idle speed (max)	5000 RPM
Cutting depth (45º)	47 mm
Cutting depth (90º)	66 mm
Saw blade included	Yes
Quantity	1
Diamond disc	-
Product color	Multicolor
Input power	1600 W
Power source	AC

Weight and Dimensions

Depth	240 mm
Width	320 mm
Height	230 mm
Weight	4300 g
