wto 4201 - Ball Nozzle Options; Copper Pipe Fitting Options

Ø 12
14
Ø 12
38
Ø 12
55
M6
70
M6
70
Ø 12
M6
Ø d
Ø D
M
M
Ø d
Ø D
M
www.wto-tools.com 15
3.7 Ball nozzle options
One-piece ball nozzles
Item No. 59145 45168 79542
Straight pipe Angular pipe Straight adaptor
Item No. 111128 111129 111126
3.8 Copper pipe fitting options
Modular ball nozzles
Item No. M ØD Ød
30549
M 10 x 1 6 4.8
31638 M 12 x 1 8 6
Item No. M ØD Ød
55753
M 8 x 1 6 4,8
47997 M 10 x 1 6 4,8
Angular type
Item No. M Item No.
97184 M 8 x 1 -
18483 M 10 x 1 26263
18529 M 12 x 1 26264
Plug screw
Straight type
Sealing ring
Dimensions in mm
