Measurement conditions
The i1Pro measurement device supports multiple measurement conditions. Depending
on how you wish to scan a target for UV you need to measure each row of your test chart
either once or twice. In a single pass scan measurement and during the first pass of the
dual pass scan measurement, the patches are illuminated with the tungsten filament
lamp in the i1Pro device. If a second pass is required the patches are illuminated with a
UV LED during the measurement.
Single Pass Measurement is required for measurement condition
s )3/-\4UNGSTENlLAMENTLAMPWITH56INCLUDED.O&ILTER
Dual Pass Measurement is required for the following measurement conditions:
s )3/-\$
s )3/-\)LLUMINATIONWITH56EXCLUDED56CUT
s /"#\82ITE/PTICAL"RIGHTENER#OMPENSATION
The Status Indicators on the i1Pro device guides you through the measurement
process.
Dual pass scan measurements require the aluminum ruler which includes the
reference required for the positioning sensor.
