975-0787-01-01 11
This section for use by qualified personnel only.
Basic Installation Procedures
This section provides sample installation information as a guide for
your installation. For your convenience, the overall procedure is
divided into these main steps:
❐ Step 1: Designing the Installation on page 12
❐ Step 2: Choosing a Location for the Unit on page 17
❐ Step 3: Mounting the Unit on page 18
❐ Step 4: Connecting the AC Input Wires on page 20
❐ Step 5: Connecting AC Output to an Existing AC Circuit on
page 24
❐ Step 6: Connecting the DC Cables on page 26
❐ Step 7: Connecting to a Remote Panel on page 32
❐ Step 8: Testing Your Installation on page 33
Freedom X Series INV Owners Guide.book Page 11 Tuesday, June 27, 2017 4:10 PM
