65 Freedom X Owner’s Guide
Specifications
NOTE: Specifications are subject to change without prior notice.
Physical Specifications Freedom X 1000 Freedom X 2000
L × W × H 13.4” (340mm) × 9.1” (232mm)× 3.7” (95mm) 14.6” (370mm) × 10.8” (275mm)× 3.9” (100mm)
Net Weight 11.5 lbs (5.2 kg) 14.7 lbs (6.7 kg)
Environmental Specifications Freedom X 1000 Freedom X 2000
Ambient Temperature:
-4 –140 ºF (-20 –60 ºC), with output derated
ab
ove 104 ºF (40 °C)
-40 –158 ºF (-40 –70 ºC)
-4 –140 ºF (-20 –60 ºC), with output derated
above 104 ºF (40 °C)
-40 –158 ºF (-40 –70 ºC)
Humidity: Operation/Storage 5–95% RH, non-condensing 5–95% RH, non-condensing
System Specifications Freedom X 1000 Freedom X 2000
Transfer relay rating 30A surge, 24A continuous 30A surge, 24A continuous
Transfer time (shore to inverter)
Transfer time (inverter to shore)
<20 milliseconds
a
a. To change the AC Transfer time (mode), see “Adjusting Feature Settings in Configuration Mode” on page 45.
<20 milliseconds with a 20-second delay
<20 milliseconds
a
<20 milliseconds with a 20-second delay
Transfer voltage (shore to inverter)
Transfer voltage (inverter to shore)
<85 V and >140 V
<135 V and >90 V
<85 V and >140 V
<135 V and >90 V
Cooling Fan, activated by any of the following:
•High internal temperature
•High AC output power
Fan, activated by any of the following:
•High internal temperature
•High AC output power
Operating Temperature Range
S
torage Temperature Range
Freedom X Series INV Owners Guide.book Page 65 Tuesday, June 27, 2017 4:10 PM
