18 Freedom Xi Owners Guide
Operating During Transition Between Shore Power and Inverter Mode
Operating Limits
Power Output
The Freedom Xi can deliver up to 1000 watts or 2000 watts of
continuous utility grade sine wave AC power. The wattage rating
applies to resistive loads such as incandescent lights.
Input Voltage
The allowable Freedom Xi input battery voltage ranges are shown
in the following table:
Operating
Condition
Battery Voltage
Range
Comment
Full
Op
erating
Range
Low:10.5–16.5 volts
Mid:11.8–16.5 volts
High:12.1–16.5 volts
Low refers to low limit of the low voltage threshold.
Mid refers to middle limit of the low voltage threshold.
High refers to high limit of the low voltage threshold.
Optimum
Perf
ormance
12.1–13.0 volts
Low Voltage
Ala
rm
Low: <11.0 volts
Mid: <12.3 volts
High:<12.6 volts
A silent low battery warning shows fault code  on
the display.
Low Voltage
Shu
tdown
Low: <10.5 volts
Mid: <11.8 volts
High:<12.1 volts
A single one-second low battery alarm beeps and the
display shows fault code . After five minutes, the
unit shuts down completely.
Instant Low
V
oltage
Shutdown
<10.2 volts After two seconds below the limit, the unit shuts down
and the low battery alarm sounds a long beep
continuously for 30 seconds.
High Voltage
Shu
tdown
16.7 volts The over-voltage alarm beeps every second and the
display shows fault code  alternating with the
battery voltage. The status LED turns red and the
display screen is turned OFF within 30 seconds to
protect itself from excessive input voltage.
NOTE: Al
though the Freedom Xi incorporates over-
voltage protection, it can still be damaged if input
voltage exceeds 16.7 volts.
