Xantrex truecharge 2 series User Manual

975-0526-01-02 33
Installing Batteries
Operating DC Loads
When the Truecharge™ 2 Battery Charger is operating, DC loads such as
fans and lights may vary in speed or intensity. This is normal. The
Truecharge™ 2 Battery Charger will not harm any load connected to it as
long as the load can withstand the following maximum voltages:
• 16 V for 12-volt chargers,
• 32 V for 24-volt chargers.
TC2 204060 Series BattChg Owners Guide.book Page 33 Friday, July 8, 2011 11:44 AM

Xantrex truecharge 2 series Specifications

General

Input Voltage	90-265 VAC
Input Frequency	47-63 Hz
Number of Banks	3
Dimensions	Varies by model
Weight	Varies by model
Output Voltage	12 VDC or 24 VDC
Output Current	20A, 40A, or 60A
Battery Types	Flooded, Gel, AGM
Charging Stages	3-stage (Bulk, Absorption, Float)
Protection Features	Overvoltage, Overcurrent, Short Circuit, Reverse Polarity, Over Temperature
Operating Temperature	-20°C to +50°C
