975-0526-01-02 7
Truecharge 2 Battery Charger Features
6 Battery Temp. Select button
• Press and hold the button for three seconds to select one of
three settings. An indicator LED corresponds to each
setting.
If an optional BTS is connected, the indicator LEDs
represent real-time battery temperature.
• When the optional BTS is not used, this selection changes
the charger's output voltage settings to compensate for the
battery temperature selected. The Cold setting raises the
voltages, and the Hot setting lowers the voltages. See
“Battery Temperature Compensation Levels” on page 32.
RISK OF BATTERY DAMAGE
Be sure the appropriate setting is selected before charging. For varying
conditions, use the Warm setting.
Failure to follow these instructions can damage the unit and/or
damage other equipment.
Item Description
Item Description
6
continued
• Cold - for battery temperature below 5 °C (41 °F); raises
the charging voltage to compensate
• Warm - for battery temperature between
5 and 30 °C (41 and 86 °F); default setting
• Hot - for battery temperature above 30 °C (86 °F);
lowers charging voltage to compensate
• When setting or cancelling an Equalization program: Press
and hold for five seconds both the Charger Mode and
Battery Temp. Select buttons.
TC2 204060 Series BattChg Owners Guide.book Page 7 Friday, July 8, 2011 11:44 AM
