40 Truecharge2 Series Battery Charger Owner’s Guide
Transitioning the Charger to ON, Standby, or Disabled
There are two ways to turn ON the Truecharge2 Battery Charger:
• Connect the batteries to the charger (i.e., charger is on standby) then
connect AC power at the source. If the batteries are not fully charged
then charging begins immediately. If the batteries are fully charged
then charging will go to either standby (two-stage) or float (three-
stage).
Or,
•Press ON/STANDBY on the optional remote panel while batteries and
AC power are both connected to the charger (from Standby).
The charger begins to charge the batteries from Standby.
There are two ways to put the Truecharge2 Battery Charger in
Standby (see Warning below):
• Disconnect AC power at the source (i.e., only the batteries are
connected) or
•Press
ON/STANDBY on the optional remote panel while batteries and
AC power are both connected to the charger (from ON).
The charger stops charging but continues to monitor the batteries.
There is only ONE way to safely turn the Truecharge2 Battery Charger
off (Disable):
◆ Disconnect the AC power at the source and disconnect all DC
batteries.
This is the only state where the Truecharge2 Battery Charger is completely
de-energized.
When the Truecharge2 Battery Charger is disabled, the optional remote
panel is inactive.
ELECTRICAL SHOCK HAZARD
• Do not disassemble the battery charger. Internal capacitors remain
charged for five minutes after all power is disconnected.
• Disconnect both AC and DC power from the battery charger before
attempting any maintenance or cleaning or working on any circuits
connected to the battery charger. See note below.
Failure to follow these instructions will result in death or serious
injury.
TC2 204060 Series BattChg Owners Guide.book Page 40 Friday, July 8, 2011 11:44 AM
