54 Truecharge2 Series Battery Charger Owner’s Guide
Specifications
NOTE: Specifications are subject to change without prior notice.
Physical Specifications
Base Unit Dimensions: L × W × H
TC2012, TC4012 250×170×70 mm (9.84×6.70×2.76 in.)
TC1024, TC2024 250×170×70 mm (9.84×6.70×2.76 in.)
TC6012, TC3024 340×170×90 mm (13.38×6.70×3.54 in.)
Weight
TC2012, TC4012 2.2 kg (4.8 lbs)
TC1024, TC2024 2.2 kg (4.8 lbs)
TC6012, TC3024 4.5 kg (9.9 lbs)
AC input connections Three color-coded No. 14 AWG wires (L, N,
GND) minimum 152 mm (6 in.) long in a
separate AC wiring enclosure with 21.3 mm
(0.84 in.) hole provision for connection of a
½ inch North American "trade size" strain
relief (included).
AC input connections
(IEC models only)
IEC 60320 C14 male connector receptacle
DC output
connections
Four M6 studs (3 positives and 1 common
negative) for battery cable ring terminals and
one M6 mm DC equipment ground
AC Input Specifications
AC input voltage range
Nominal:
Full Performance:
Automatic derating to
80% output:
120 Vac, 230 Vac, 240 Vac
104 – 265 Vac ±4 Vac
90 – 108 ±4 Vac
Max. AC input current
TC2012:
TC4012:
TC6012
TC1024:
TC2024:
TC3024
3.9 A
7.7 A
11.6 A
3.9 A
7.7 A
11.6 A
Power factor at rated
load
≥0.95
Frequency 47 – 63 Hz
Efficiency – peak
12/24-volt units:
12/24-volt units:
80% @ 120 Vac
84% @ 230 Vac
Surge protection Line-to-neutral surge protector rated at
275 Vac
TC2 204060 Series BattChg Owners Guide.book Page 54 Friday, July 8, 2011 11:44 AM
