Xantrex Truecharge2 User Manual

975-0526-01-02 55
Specifications
DC Output Specifications
Number of isolated battery
bank outputs
3 separated outputs
DC output voltage range
including dead battery
charging voltage
12-volt units:
24-volt units:
0 – 16 Vdc
0 – 32 Vdc
Maximum equalization
voltage
12-volt units:
24-volt units:
16 Vdc
32 Vdc
Voltage accuracy (no load)
12-volt units:
24-volt units:
14.4 ±0.1 Vdc @ 25 °C (77 °F)
28.8 ±0.2 Vdc @ 25 °C (77 °F)
Nominal battery voltage
12-volt units:
24-volt units:
12 Vdc
24 Vdc
Normal operating output
range
12-volt units:
24-volt units:
0 – 16 Vdc
0 – 32 Vdc
Maximum DC output
current (total)
TC2012:
TC4012:
TC6012
TC1024:
TC2024:
TC3024:
20 +10% A
40 +10% A
60 +10% A
10 +10% A
20 +10% A
30 +10% A
Absorption voltage:
Flooded
GEL
AGM
Lead-calcium
12-volt units 24-volt units
25 °C (77 °F) 25 °C (77 °F)
14.4 ±0.1 28.8 ±0.2
14.2 ±0.1 28.4 ±0.2
14.3 ±0.1 28.6 ±0.2
15.5 ±0.1 31.0 ±0.2
DC Output Specifications
TC2 204060 Series BattChg Owners Guide.book Page 55 Friday, July 8, 2011 11:44 AM
