About This Guide
Purpose
The purpose of this Guide is to provide explanations and procedures for installing,
configuring, operating, and troubleshooting the XW Solar Charge Controller (XW
SCC).
Scope
This Guide provides safety guidelines, detailed planning and setup information,
procedures for installing the unit, as well as information about operating and
troubleshooting the unit. It does not provide details about particular brands of
photovoltaic (PV) panels. You need to consult individual PV manufacturers for
this information.
Audience
This Guide does not provide sufficient information for anyone but a qualified
installer to install this product. Installers should be electricians or technicians fully
educated on the hazards of installing electrical equipment. The monitoring and
operation information in this manual is intended for anyone who needs to operate
the XW Solar Charge Controller.
Organization
This Guide is organized into five chapters and two appendices.
Chapter 1 describes features and functions of the XW Solar Charge Controller.
Chapter 2 contains information and procedures to install the XW Solar Charge
Controller. Before installing the XW SCC, read this entire chapter. Depending on
your installation, you may need to perform certain installation stages in a different
order than the order presented in this chapter.
Chapter 3 contains information and procedures to configure the XW Solar Charge
Controller.
Chapter 4 contains information about the operation of the XW Solar Charge
Controller.
Chapter 5 contains information about identifying and resolving possible problems
with systems using a XW Solar Charge Controller.
Appendix A provides the specifications for the XW Solar Charge Controller.
