XE210/XE230/XE260C Hydraulic Excavator Operating and Maintenance Manual 52
Monitor
Fig. 1-28 Picture of monitor interface
List 1-3 List of illustrated signals
Serial
No.
Name
Signal
Function
1
Indication interface of screen
Screen indication or main menu catalogue(for
details, see the latter introduction)
2
Alarm of hydraulic liquid
temperature
On for a high temperature
3
Air filter blockage alarm
On for a blockage in the air filter
