Xeno XDR5 real time DVRs manual V1.0
4.2.3 Using an Auxiliary Monitor
Certain features of the Live View are also available while in an Aux monitor. These features include:
• Camera: Switch to a full screen display of the selected camera. Camera can be selected from a dropdown list.
• Multi-screen: Switch between different display layout options. Layout options can be selected from a
dropdown list.
• Previous: When displaying less than the maximum number of cameras in Live View, clicking this feature will
switch to the previous set of displays.
• Next: When displaying less than the maximum number of cameras in Live View, clicking this feature will switch
to the next set of displays.
• Play: Enter into Playback mode.
• Log off: Logout the current user who already logged in.
Note: In the live view mode of the main output monitor, the menu operation is not available while in Aux output
mode.
4.2.4 Quick Setting Toolbar in Live View Mode
On the screen of each channel, there is a quick setting toolbar which shows when you point the mouse to the bottom of
the screen.
Figure 3.2 Quick Setting Toolbar
Table 3.4 Description of Quick Setting Toolbar Icons
Instant Playback only shows the record in last few minutes.
Digital Zoom can zoom in the selected area to the full screen. Left-click and drag the red box for target zooming in
area, as shown in Figure 3.3.
