MEDIA
12 XES SYNERGIX 8850 PRINTER OPERATOR MANUAL
11. Squeeze the lever at the end of the media roll support tube
and position the tube until the size indicators on the tube
match the size of the roll.
• For example, if the media roll is 36 inches, the ends of the
media roll should be at the 36-inch markers on the media
roll support tube.
12. Place the new media roll into the media drawer so that the
lead edge of the paper is on the underside of the roll and
toward the printer.
13. Position the media roll support tube so that the ends of the
tube rest within the support rollers at the sides of the drawer.
• Ensure that the tube falls into place within the support
rollers.
14. Remove the tape from the lead edge of the media roll.
15. If the lead edge of the media roll contains debris from the
adhesive or is torn or uneven, trim the lead edge.
NOTE: Trimming is not usually necessary for a new roll of
media.
