5. Load the labels in the tray.
• For long-edge feed, insert labels face up with the top edge toward the front.
• For short-edge feed, insert labels face up with the top edge toward the right.
Note: Do not load paper above the maximum fill line. Overfilling can cause paper jams.
6. Adjust the length and width paper guides to fit the labels.
7. Slide the tray back into the printer.
Xerox
®
AltaLink
®
B81XX Series Multifunction Printer
User Guide
207
Paper and Media

Xerox AltaLink B8145 Specifications

General

Print Technology	Laser
Print Speed	Up to 45 ppm
Maximum Print Resolution	1200 x 2400 dpi
Automatic Duplexing	Yes
Scan Resolution	600 x 600 dpi
Control Panel	10.1-inch color touchscreen
Copy Resolution	600 x 600 dpi
Memory	4 GB
Scanner Type	Flatbed
Connectivity	Ethernet, USB, NFC
Functions	Print, Copy, Scan, Fax
Paper Sizes	A4, A5, B5, Legal, Letter
Hard Drive	320 GB
Mobile Printing	Apple AirPrint, Mopria, Xerox Print Service Plug-in for Android
Weight	80.6 kg
