Caution: Do not plug or unplug the power cord while the printer is powered on.
RReessttaarrttiinngg,, PPllaacciinngg iinn SSlleeeepp MMooddee,, oorr PPoowweerriinngg OOffff
tthhee PPrriinntteerr
To restart the printer, place the printer in Sleep Mode, or power off the printer:
1. At the printer control panel, press the Power/Wake button.
2. Select an option:
• To restart the printer, touch Restart.
• To place the printer in Sleep Mode, touch Sleep.
In Sleep Mode, the touch screen goes dark and the Power/Wake button pulses.
• To power off the printer, touch Power Off.A Please Wait message appears as the printer
powers off.
3. If you want to power off the printer for an extended period, open the printer front door, then
power off the main power switch.
Caution: Do not unplug the power cord while the printer powers down.
38
Xerox
®
AltaLink
®
B81XX Series Multifunction Printer
User Guide
Getting Started

Xerox AltaLink B8170 Specifications

General

Category	All in One Printer
Memory (Standard)	8 GB
Energy Star Certified	Yes
Functions	Print, Copy, Scan, Fax
Hard Drive	320 GB
Duplex Printing	Yes
Connectivity	Ethernet
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Network Connectivity	Ethernet
Operating System Compatibility	Linux
Print Speed (Black)	Up to 70 ppm
Copy Speed	Up to 70 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
