Pre drilled stock LEF is not supported by The GBC
®
AdvancedPunch™, however predrilled stock may be run
using SEF
Due to the nature of punching holes, each punched sheet is slightly deformed, and when stacked, the edge
with the holes will have an increased height as compared to the non-punched edge.
o Reduced stack quality may be experienced due to variability in the punch hole formation.
o The stack height can be effected by many factors, such as: paper type, quality, weight and
curl, as well as die type, age and condition. Paper curl is best when it has a slight downward
curl on the edges. This can be adjusted by the operator while running prints.
A4 and LTR punch units are not the same; therefore, A4 and LTR die sets are not interchangeable.
The LTR punch unit will be shipped with the 19-hole punch die.
The A4 unit will ship with the 21-hole punch die.
Additional punch dies are available for order (see below)
Up to 3 additional die sets can be stored inside the GBC
®
AdvancedPunch™.
Punch Dies
The GBC
®
AdvancedPunch™ is capable of punching a variety of hole-punch patterns by simply changing the
punch die. Punch dies can be changed in seconds without tools. The punch dies currently available are listed
below. Each die set has a 90 day warranty from date of purchase.
In the Western Hemisphere (8 ½ x 11 inch) punch dies are ordered using the Supplies ordering process; in
Europe (A4) punches are ordered through sales representatives; please check for availability.
A4 and Letter version die sets are not interchangeable.
Please note: Punch die life will be increased if the wick material is lightly oiled every 50,000 punch cycles
(approximately every month) with quality machine oil such as 3-in-1 Oil. Small deposits of oil will be observed
around the perimeter of the punched holes until the excess oil is absorbed (usually within 20 sheets).
8 1/2 in. x 11 in. Punch Dies
