Xerox DocuMate 152i User Manual

User Guide 5
Assemble the Scanner
1. Remove the scanner and parts from the protective foam and plastic bags.
2. Remove any shipping tape from the scanner and input tray.
3. Insert the input tray extension into the input tray and snap the tabs into place.
4. Open the ADF cover and carefully remove any foam particles that may have gotten inside it.
Leave the cover open so you can attach the input tray.
5. Align the tabs on the input tray with the slots inside the scanner and slide the tray down into
place. Push the tray back until it is fully seated into position.

Xerox DocuMate 152i Specifications

General

ADF Capacity	50 sheets
Connectivity	USB 2.0
Duplex Scanning	Yes
Scanning Technology	CIS (Contact Image Sensor)
Color Depth	24-bit
Max Document Size	8.5" x 14"
Maximum Document Size	8.5" x 14"
Supported Operating Systems	Windows
Optical Resolution	600 dpi
