Xerox FaxCentre F116 User Manual

- 102 -
Maintenance
Date en cours : 11 août 2004
\\Sct01002\BE31-DOC\DOC 31 - En cours\Travaux en cours\Fax\MFL V 2\LU 251 523 984B MFL_V2 FAXCENTRE F116_F116L XEROX
FR_GB_ESP\Anglais\Maintenance.fm
Replacing the drum cartridge
To replace the drum cartridge, proceed as shown below:
When the display shows:
 1 - Press the release button of the upper cover to open it.
Caution - The fusing assembly located inside the machine may become very hot during
operation. To avoid injury - do not touch
 2 - The drum cartridge is under the toner cartridge. Remove the toner cartridge from its housing
and place it safely out of the way.
 3 - Remove the used drum cartridge and take the new one out of its package.
CHANGEDRUM
<OK> TO CONFIRM
2
1
MFL 251 523 984_ FAXCENTRE F116_F116 L US.book Page 102 Mercredi, 11. août 2004 4:48 16
