Left al Right 85 on Pica
Present margin
Self demonstration
for service
Prints out all characters, space, back
space,correction, carrier return,
relocation express
Dimension
Weight
2. General characteristics
Width 491 mm (19.3 in)
Length 376 mm (14.8 in)
Height 137 mm ( 5.4 in)
9 kg
This electronic typewriter model ELECTRONIC COMPACT consists of
the following six major assemblies
L
- Chassis and platen unit
- Keyboard
- Printer assembly
with typewheel motor, hammer solenoid, photo interrupters for
typewheel and printer home position, ribbon feed mechanism,
correction mechanism
- Power pack
to transform AC to regulated DC
- Control Print Circuit Board
with 8 bit microcomputer for controlling all functions, driver
device for stepping motors and hammer solenoid, buzzer
- Housing
