Main Components and Their Functions
Phaser® 6180 Color Laser Printer
2-2
Main Components and Their Functions
This section includes:
■ Front View on page 2-2
■ Rear View on page 2-3
■ Internal View on page 2-3
Front View
1. Front door A
2. Output tray
3. Control panel
4. Button A for opening the front door
5. Power switch
6. Tray 1 (MPT)
7. Paper tray
8. Optional 550-sheet feeder
