Xerox Phaser 6180 - Rear View; Internal View

Main Components and Their Functions
Phaser® 6180 Color Laser Printer
2-3
Rear View
Internal View
1. Power cord connector
2. USB port
3. Parallel port
4. Optional memory slot
5. Multi protocol network card (MPC)
6. Network connector
1. Fuser
2. Print cartridge
3. Transfer unit
4. Button A for opening the front door
1. Duplex unit
6180-002
1
2
3
6
4
5
6180-003
1
2
3
4
6180-004
1
